1/10 SCX10 III Jeep JT Gladiator with Portals RTR Gray

Introduction

Part # AXI03006BT1

Features:

• Replica V8 engine cover, transmission housing and transfer case cover and protect the motor while improving scale appearance and adding forward-mounted weight.
• AR45 Portal Axles feature an offset front housing for realistic looks.
• Axle housings also use portal gears for increased ground clearance and a universal that provides 45 degrees of steering.
• Differential locker features Hypoid gears, allowing for smaller size gears, improved gear reduction and reduced torque twist.
• Centered battery position improves chassis balance with front-mounted motor.
• Hard anodized oil-filled shocks feature shock cap with bleed screw for easier rebuilds.
• Improved materials increase durability and stiffness while holding tighter tolerances to eliminate most “slop”.
• Extended 13.9 inch wheelbase with longer frame rails and chassis supports a more realistic version of the Jeep JT Gladiator body.

Includes:

• (1) Axial SCX10 III Jeep JT Gladiator 4WD with:
• (1) Spektrum Firma Smart 40A ESC/Receiver (installed)
• (1) Spektrum 15kg Servo (installed)
• (1) Spektrum DX3 DSMR Radio
• (1) Product Manual

Specifications:

• Scale:1/10

• Length:22.25in (565 mm)

• Width:9.25in (235 mm)

• Height:9.5in (241 mm)

• Ground Clearance:3in (76.2mm)

• Wheelbase:13.9in (353 mm)

• Weight:7lbs (3175g)

• Drivetrain:4WD

• Gear Pitch:32-Pitch

• Pinion:14T

• Spur Gear:40T

• Final Drive Ratio:45.6:1 Low / 31.3:1 High

• Max Battery Dimensions:5.45×1.83×1.38in (138.5×46.5x35mm)

• Completion Level:Ready-To-Run

Needed to Complete:

• Vehicle Battery (accepts standard and shorty packs)
• Compatible charger
